Features
• Up to 2560×1440@25fps
• Cable Free Design
• H.265/H.264 HP/MP/BP/M-JPEG Codec
• Min. Illumination Color: 0.05 Lux,B/W: 0.01 Lux, 0 Lux with IR
• IE,Chrome,Firefox, Safari, Plug-in Free
• Mechanical WDR 120dB
• Smart IR, IR Range: 25m
• VCA Tripwire/Double Tripwire/Perimeter/Object Abandon/Object
• Interface MicroSD Card Slot, up to 128GB, Reset Button
• TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V), IP67
• Operating Conditions -35℃～60℃(IR OFF) /-35℃～40℃(IR ON), 0～95% RHG
• Case Material Metal
• CE, FCC
Specifications
| Camera | |
| Image Sensor | 1/3″ CMOS |
| Core Processor | ARM7 Architecture |
| Operating System | Embedded Linux |
| Min. Illumination | Color: 0.05Lux(F1.2,AGC ON) |
| B/W: 0.01Lux(F1.2,AGC ON); 0Lux with IR | |
| Shutter Time | 1s～1/100000s |
| Lens | 4mm, Angle of View: 82.7° |
| Lens Mount | φ12 |
| Auto Iris | N/A |
| Day& Night | IR Cut Filter with Auto Switch |
| Wide Dynamic Range | 120 dB |
| DNR | 3D |
| S/N Ratio | >60dB |
| Compression Standard | |
| Video Compression | S+265/ H.265/ S+264/ H.264 H/ H.264 M/ H.264 B/ M-JPEG |
| Video Bit Rate | 32Kbps~16Mbps |
| Audio Compression | G.711A/G.711U/ADPCM/AAC |
| Audio Bit Rate | G711 8KHz, 64kbps |
| ADPCM 8KHz, 32kbps | |
| AAC 48KHz, 96-320kbps | |
| Image | |
| Max. Image Resolution | 1440P(2560×1440)@25fps |
| Frame Rate | PAL：1440P@25fps,QXGA@25fps |
| NTSC：1440P@25fps,QXGA@30fps | |
| Triple Stream | Mainstream: 1440P(2560×1440) |
| Substream: D1(704×576) | |
| 3rd Stream: CIF(352×288) | |
| Image Settings | Brightness, Saturation, Contrast, Sharpness, Image Enhencement |
| HLC | Y |
| Smart Defog | Y |
| Corridor Format | Y |
| EIS | Y |
| ROI | 4 Zones |
| Privacy Mask | 4 Zones |
| Picture Overlay | 200 × 200, BMP 24bit, Zone Configurable |
| OSD | 16×16, 32×32, 24×24, 48×48, 64×64, 96×96 Size Letters Such as |
| Week, Date, Time, Total 5 Regions | |
| Network | |
| Browser | CHROME V45 or lower, IE, FIREFOX |
| Network Storage | FTP |
| NTP | Y |
| ANR | Y |
| Video Analytics(VCA) | Tripwire/Double Tripwire/Perimeter/Object Abandon/Object |
| Lost/Running/Loitering/Parking/Crowd/Audio Abnormal Detection/ | |
| Video Abnormal Detection | |
| Alarm Trigger | Motion Detection/IP Conflict/MAC Conflict/Port Alarm/Mask Alarm |
| Protocols | IPv4/IPv6/HTTP/802.1x/FTP/SMTP/UPnP/SNMP/DNS/DDNS/ICMP/IGMP |
| /NTP/RTSP/TCP/UDP/DHCP/PPPoE/HTTPS/ARP/RTP/QoS/MULITCAST | |
| User Permission | 4 Level/8 Users |
| Remote Connection | 5 Users Access at the Same Time |
| System Compatibility | ONVIF (Profile S), SDK, CGI |
| Interface | |
| Audio Input | N/A |
| Audio Output | N/A |
| Ethernet | 1-ch RJ45 10M / 100M Ethernet Interface |
| Alarm Input | N/A |
| Alarm Output | N/A |
| Video Output | N/A |
| On-board Storage | MicroSD Card Slot, up to 128GB |
| Reset | Y |
| General | |
| Language | English,Spanish,Korean,Italian,Turkish,Thai,Russian,Traditional Chinese |
| Simplified Chinese,Polish,French | |
| Operating Conditions | -35℃～60℃(IR OFF) /-35℃～40℃(IR ON), 0～95% RHG |
| Power Supply | DC 12V±10%/PoE |
| Power Consumption | Max. 5W(IR OFF) (ICR Instant Switch 8.5W) |
| Max. 7W(IR ON) | |
| Circuit Protection | TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V) |
| Impact Protection | IP67 |
| IR Range | 25m |
| IR LEDs | 2pcs Array |
| Dimensions | 189mm×70mm×70mm |
| Weight | 0.7KG (IP Camera Only); 0.9KG (with Packing Box) |
| S+265: | Tiandy enhanced H.265 codec |
| ANR: | Auto store video in SD card when NVR disconnected, and upload video to |
| NVR when resumed connection(Only Support Tiandy ANR NVR) | |
