JL305-series offers an unprecedented level of accuracy, security and continuous processing of large volumes of banknotes. JL305-series is approved by European Central Bank (ECB).
Functions
√ Counting
√ Denomination
√ Multi-currency
√ Facing and Orientation
√ Issue Splitting
√ Authentication
√ Fitness Sorting: Soil, Holes, Tears, Tape, etc.
√ Serial Number Capturing
Product Highlight
- Stackers push-out banknote automatically when banknote quantity reach preset batch value, which improves sorting productivity with 50%. This technology with patent certification to ensure “Non-Stop Operation”
- Linear and roller banknote transport structure with patent certification and fully open banknote transport, which can be used to deal with damaged, old and small denomination banknote. It makes an easy maintenance and a quick jam removal.
- Modularization multi-sensor recognition technology helps to identity high quality counterfeit banknote and forgery banknote with high-precision.
- Serial number identification and information tracing are available and cash circulation management system is optional.
- The LAN, RS-232 and USB interface extend the connectivity of JL305, which can be connected with external printer and PC for sorting report checking, printing and upgrading, to realize centralized management.
Six Configurations Available
The JL305-series offers 6 configurations to suit banknote processing requirement.
Software System
LINUX operation system makes JL305 became extensible and configurable. Printer and computer can be connected to our sorting machine with a cable. Users are able to read, upload, print operator number, working time and banknote information, and also can save the information needed to computer. With our software, JL305 is capable of serial number reading, recognition and comparison, black list setting, counterfeit currency tracing and management, and bar code reading.
Technical Information
| Capacity: | 1,000 notes (continuous feeding/non-stop feeding) |
|---|---|
| NV Technology: | CIS, UV, Magnetic, IR |
| Speed Range: | Counting 800 notes/min, Sorting 720 notes/ min, S/N Reading 720 notes/ min |
| Banknote Size Range: | Width 53-85 mm, Length115-180 mm |
| Display: | 6.4″or 9.7″ TFI Color Display |
| Interface: | LAN, RS232, USB |
| Operating System: | LINUX |
| Power Supply: | AC 198-242V 50/60HZ |
| Power Consumption: | 300 W |
| Dimensions: | 330×405×430mm(W×D×H) |
| Weight: | 28Kg |
| Manufacturing Standards and Approvals: | ISO9001, CE, RoHS |
| Accessories: | Additional Currencies, Remote Display, Integral Printer, Ticket in/ Ticket out (TITO), Clearance Program, Serial Number Printing. |
