Features

• Up to 2560×1440@25fps

• Cable Free Design

• H.265/H.264 HP/MP/BP/M-JPEG Codec

• Min. Illumination Color: 0.05 Lux,B/W: 0.01 Lux, 0 Lux with IR

• IE,Chrome,Firefox, Safari, Plug-in Free

• Mechanical WDR 120dB

• Smart IR, IR Range: 20m

• VCA Tripwire/Double Tripwire/Perimeter/Object Abandon/Object

• Interface Bulit-in Mic,Audio in/out 1/0,MicroSD Card Slot, up to 128GB, Reset Button

• TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V), IP67

• Operating Conditions  -35℃~60℃(IR OFF) /-35℃~40℃(IR ON), 0~95% RHG

• Case Material Metal

• CE, FCC

Specifications

Camera
Image Sensor 1/3″ CMOS
Core Processor ARM7 Architecture
Operating System Embedded Linux
Signal System PAL/NTSC
Min. Illumination Color: 0.05 Lux @(F1.2, AGC ON)
B/W: 0.01Lux @(F1.2, AGC ON); 0 Lux with IR
Shutter Time 1s~1/100000s
Lens 2.8mm, Angle of View: 99°
Lens Mount φ12
Auto Iris N/A
Adjustment Range Pan:0° – 355°, Tilt: 0° – 75°, Rotation: 0° – 355°
Day& Night IR Cut Filter with Auto Switch
Wide Dynamic Range 120 dB
Digital Noise Reduction 3D DNR
S/N Ratio >60dB
Compression Standard
Video Compression S+265/H.265/H.264H/H.264M/H.264B/MJPEG
Encode Type High Profile/Main Profile/Base Line Profile
Video Bit Rate 32Kbps~16Mbps
Audio Compression G.711A/G.711U/ADPCM/AAC
Audio Bit Rate G711 8KHz, 64kbps
ADPCM 8KHz, 32kbps
AAC 48KHz, 96-320kbps
Frame Rate PAL: 1440P@25fps, QXGA@25fps
NTSC: 1440P@25fps, QXGA@30fps
Triple Stream Mainstream:1440P(2560×1440)
Substream: D1(704×576)
3rd stream: CIF(352*288)
Image Settings Brightness, Saturation, Contrast,Flip Mode Adjustable by Client Software or Web Browser
HLC Y
Smart Defog Y
Corridor Format Y
EIS Y
ROI 4 Zones
Privacy Mask 4 Zones
Picture Overlay 200 × 200, BMP 24bit, Zone Configurable
OSD Size:16×16, 32×32, 24×24, 48×48, 64×64, 96×96
Letters, Week, Date, Time, Total 5 Regions
Network
Browser IE8/Firefox24 or above
Network Storage FTP
NTP Y
ANR Y, Auto store video in SD card when NVR disconnected, and upload video to NVR when resumed connection(Only Support Tiandy ANR NVR)
Video Analytics Tripwire/Double Tripwire/Perimeter/Object Abandon
Object Lost/Running/Loitering/Parking/Crowd
Audio Abnormal Detection/Video Abnormal Detection
Alarm Trigger Motion Detection/IP Conflict/MAC Conflict/Port Alarm/Mask Alarm
Protocols IPv4/IPv6/HTTP/802.1x/FTP/SMTP/UPnP/SNMP
DNS/DDNS/NTP/RTSP/TCP/UDP/DHCP/PPPoE
HTTPS/ARP/RTP/QoS/BONJOUR/MULITCAST/ICMP/IGMP
Remote Connection 5 Users Access at the Same Time
NTP Y
System Compatibility ONVIF (Profile S), SDK, CGI
Interface
Audio Input 1-ch, Mic in
Audio Output N/A
Communication Interface 1-ch RJ45 10M / 100M Ethernet Interface
Alarm Input N/A
Alarm Output N/A
Video Output N/A
On-board Storage MicroSD Card Slot, up to 128GB
Reset Y
General
Language English,Spanish,Korean,Italian,Turkish,Thai,Russian
Polish,French,Traditional Chinese,Simplified Chinese
Power Supply DC 12 V ± 10%, PoE (802.3af)
Power Consumption Max. 5W(IR OFF) (ICR Instant Switch 10W)
Max. 7W(IR ON)
Circuit Protection TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V)
Impact Protection IP67, IK10
IR Range 20m
IR LEDs 8pcs Array
Dimensions 120mm×120mm×90mm
Weight 0.7KG (IP Camera Only); 0.9KG (with Packing Box)
S+265: Tiandy enhanced H.265 codec
ANR: Auto store video in SD card when NVR disconnected, and upload video to
NVR when resumed connection(Only Support Tiandy ANR NVR)
