Camera
Image Sensor 1/2.7″ CMOS
Core Processor ARM9 Architecture
Operating System Embedded Linux
Signal System PAL/NTSC
Min. Illumination Color: 0.02Lux
B/W: 0.01Lux
Shutter Time 1s to 1/100,000s
Lens 2.8mm
Auto Iris N/A
Wide Dynamic Range Y
Digital Noise Reduction 3D DNR
Compression Standard
Video Compression H.264/M-JPEG
Video Bit Rate 32Kbps~8Mbps
Max. Image Resolution 1920×1080
Frame Rate PAL:1080p@15fps; NTSC:1080P@15FPS
couple Stream Mainstream:1080P(1920*1080)
Substream:D1(704*576)
Image Settings Brightness, Saturation, Contrast,Flip Mode Adjustable by Client Software or Web Browser
HLC Y
Smart Defog Y
OSD 16×16, 32×32, 24×24, 48×48, 64×64, 96×96 Size Letters Such as Week, Date, Time, Total 1 Regions
Network
Browser built-in web server
NTP Y
Alarm Trigger Motion Detection/IP Conflict/MAC Conflict/Port Alarm/Mask Alarm
Protocols TCP/UDP/HTTP/MULTICAST/UPnP/DHCP/DDNS/FTP/NTP/RTSP/SMTP
User Permission 4 Level/8 Users
System Compatibility ONVIF (Profile S)
Interface
Audio Input N/A
Audio Output N/A
Communication Interface 1-ch RJ45 10M / 100M Ethernet Interface
Alarm Input N/A
Alarm Output N/A
Video Output N/A
General
Language English,Simplified Chinese
Operating Conditions  -30℃~60℃, 0~95% RHG
Power Supply DC 12 V ± 20%, POE
Power Consumption Max. 3.5W(IR OFF) (ICR Instant Switch 5.5W)
Impact Protection IP66
IR Range 20m
Dimensions 131.5mm(diameter)*103(height)
Weight 0.5KG
